DMG MORI NMV 5000 DCG
MACHINING CENTERS, VERTICAL
| X Travel | 28.7" |
| Y Travel | 20.1" |
| Z Travel | 20.1" |
| Spindle Speed | 12000 rpm |
| Tool Capacity (ATC) | 61 |
| Main Horse Power | 30/25 |
| Spindle Taper | CAT 40 |
| 5 Axis Programmable Axis's | Full 5 Axis's Contouring |
| Table Type C-Axis Table Rotation | .001 |
| Coolant Thru | Yes |
| Coolant Thru High Pressure | Yes |
| Hi Pressure Coolant System | 1000 psi |
| Tool Probe/Auto Tool Length Measurement | Yes |
| B-Axis (Table Swivel) | +160̊/180̊ |
| Rapid Traverse Rates: X Axis Y Axis Z Axis | X, Y 1,968 Z AXIS 1,574 |
| Control | CNC (FANUC 31i - 5X) |
NC SYSTEM FS-31I A5 (W/ MAPPS 3) FULL 5 AXIS
SPINDLE RPM 12000
SPINDLE HIGH-OUTPUT)
SPINDLE TAPER (CAT #40)
TOOL STORAGE CAPACITY 61
TABLE TYPE T-SLOT
B-AXIS ROTATION
TABLE 1 SPEED
CHIP DISPOSAL DIRECTION - REAR DISPOSAL TYPE
EXTERNAL CHIP CONVEYOR OUTSIDE MACHINE - SCRAPER (DRUM FILTER TYPE)
THROUGH-SPINDLE COOLANT SYSTEM SIDE-THROUGH
THROUGH-SPINDLE COOLANT SYSTEM (UNIT)
THROUGH-SPINDLE COOLANT SYSTEM (UNIT) TYPE
X-AXIS SCALE HEIDENHAIN
Y-AXIS SCALE HEIDENHAIN
X-AXIS SCALE HEIDENHAIN
MANUAL PULSE HANDLE
ROTARY TABLE OFFSET DYNAMIC FIXTURE
WORKPIECE SETTING ERROR COMPENSATION
INVERSE TIME FEED PROVIDED
PART PROGRAM (320 M)
REMOTE COMMUNICATION FUNCTION FAST DATA SERVER
ATA FLASH MEMORY CARD PROVIDED
USER MEMORY AREA(BUILT-IN MAPPS) 50 MB
NUMBER OF TOOL OFFSET PAIRS 64 PC
TOOL DIAMETER COMPENSATION FOR 5-AXIS MACHINING
NUMBER OF WORK COORDINATE SYSTEM PAIRS 48
ADDITION OF OPTIONAL BLOCK SKIP SOFT-KEY TYPE
PROGRAM RESTART PROVIDED
NUMBER OF CUSTOM MACRO COMMON VARIABLES 100
AI CONTOUR CONTROL 2 PROVIDED
TILTED WORKING PLANE COMMAND PROVIDED
TOOL UP-TO-DATE POINT CONTROL FOR 5-AXIS MACHINING
CUTTING POINT COMMAND
NANO SMOOTHING
NANO SMOOTHING FOR 5-AXIS MACHINING
TOOL LIFE MANAGEMENT PROVIDED
LOAD MONITOR C (SOFT-KEY TYPE)
CUSTOMER FACTORY VOLTAGE (V) 220 V
FREQUENCY (HZ) 60 HZ
SETTING UNIT INCH
UL LABEL PROVIDED
