MAZAK QTN 250 II
CNC LATHES 2 AXIS.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
MAZAK QTN 250-II HAS A MATRIX CONTROL, 10" CHUCK, TAILSTOCK, CHIP CONVEYOR, AND MISCELLANEOUS TOOLHOLDERS.
| Max. Swing | 26.57" |
| Max Turning Diameter | 18.73" |
| Spindle Bore/Max Bar Capacity | 3.46"/ 3.0" |
| Z Travel | 20.25" |
| X Travel | 7.5" |
| Machining Length | 19.85" |
| Chuck Size | 10" |
| Chuck Type | Hydraullic |
| Spindle Motor | 35 hp |
| Spindle Speeds (RPM) | 4000 |
| Spindle Bore | 3.46 in |
| Max. Bar Capacity | 3.06" |
| Turret Tool Positions | 12 |
| Tailstock | Yes |
| Chip Conveyor | Yes |
| Parts Catcher | No |
| Control | CNC (MAZATROL MATRIX NEXUS) |
| Dimensions | 108” x 74” x 75” (w/o Conveyor) |
| Weight | 11,000LBS |
MAZATROL MATRIX CNC CONVERSATIONAL CONTROL
EIA/ISO INPUT FUNCTION
PROGRAMMABLE TAILSTOCK
CHIP CONVEYOR
ALL AVAILABLE MANUALS
MISC SELECTION OF TOOL HOLDERS (NOT ALL IN PHOTO AVAILABLE)
10" 3 JAW HYDRAULIC CHUCK
