2018 MAZAK INTEGREX i-200S/ 1000
CNC LATHES MULTI AXIS
2018 MAZAK INTEGREX i-200S WITH SMOOTH X CONTROL, 110 TOOL ATC, AUTOMATIC PARTS, CATCHER, ATS BARFEEDER, LNS TURBO CHIP CONVEYOR AND 213 PSI CTS.
| Maximum Swing | 25.9" |
| Max Turning Diameter | 25.9" |
| Main Spindle Bore/Max Bar Capacity | 2.99"/ 2.5" |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Swing Over Cross Slide | 25.9" |
| Distance Between Centers | 40" |
| Maximum Cutting Length | 39.8" |
| X-Axis Travel (X1, X2, X3) | 24.21" |
| Z-Axis Travel (Z1, Z2, Z3) | 42.4" |
| Y-Axis Travel (Y1, Y2, Y3) | 9.84" |
| C-Axis Indexing (1, 2) | 0.0001/ 0.0001 DEG |
| W-Axis Travel Sub Spindle | 41.97 in |
| Main Spindle Chuck Size | 8" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.99" |
| Main Spindle Maximum Bar Work | 2.5" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 20/ 25 |
| Sub Spindle/2nd Spindle Chuck Size | 8 |
| Sub Spindle/2nd Spindle Bore Size | 2.5 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 20/ 25 |
| Main & Sub Spindle Synchronization | Yes |
| ATC Magazine Capacity | 110 |
| B-Axis Head Indexing | 0.0001 deg |
| B-Axis Milling Spindle Speed | 12000 rpm |
| B-Axis Milling Spindle Horse Power | 30 |
| Bar Feed | Yes |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Milling Spindle Synchronous Tapping | Yes |
| Coolant Thru Milling Head | Yes |
| High Pressure Coolant System (PSI) | 213 |
| Control | CNC (MAZATROL SMOOTH X) |
| Dimensions | 193.3" X 110.2" X 107 |
| Weight | 35,596 lbs |
MAZATROL SMOOTH X CONTROL
19" COLOR LCD
EIA/ ISO PACKAGE
3-D COORDINATE CONVERSION
G00 SLOPE CONSTANT
CYLINDRICAL & POLAR COORDINATE
MILLING-SPINDLE SYNCHRONOUS TAPPING
INCH/ METRIC CONVERSION
Y-AXIS CONTROL
INTELLIGENT SAFETY SHIELD (AUTO & MANUAL OPERATION)
ABSOLUTE POSITIONING SYSTEM
X, Y, Z PITCH ERROR COMP INPUT
COOLANT THROUGH MILLING HEAD
213 PSI THRU-SPINDLE COOLANT
C-AXIS 0.0001 1ST & 2ND SPINDLE
CHUCK AIR BLAST
8" THRU-HOLE CHUCK B-208A615/ 1ST SPINDLE
8" CHUCK B-208 - 2ND SPINDLE WITH NON-THRU HOLE CYL
ROYAL A2-6, QG-65 COMPACT COLLET CHUCK & QUICK GRIP COLLET
CHUCK AIR BLAST - 1ST SPINDLE
TURRET AIR-BLAST (FLOOD COOLANT NOZZLE)
110 TOOL ATC - CAPTO
12,000 RPM ROTARY TOOL
B-AXIS 0.0001 DEGREE
AUTOMATIC TOOL EYE
AUTO CHUCK JAWS OPEN/ CLOSE
OPERATOR DOOR INTERLOCK
HYDRAULIC PRESSURE INTERLOCK
COOLERS FOR BALL SCREWS
TEST BAR - CAPTO C6 - 40mm X 180mm LONG
SMOOTH ENGRAVING FUNCTION
TOOL LENGTH COMP IN TOOL AXIS DIRECTION
SMOOTH CAM RS (ENG #93904)
LNS ML-580 BARFEEDER
LNS TURBO MICRO HINGE 250 CHIP CONVEYOR (40")
